B81.81

Scroll to learn more

A professional range of machines designed for smaller, lightweight tractors. Requiring only a mass of 4900kg for the tractor, this range of arm mowers really gives the contractor true flexibility.

The 3 arm arrangement gives a versatile reach characteristic, allowing cutting over obstacles such as fences and guard rails.

Key Features

  • 8.1m reach
  • 1.2m or 1.5m cutting heads
  • Oil cooled as standard
  • ICS fully proportional controls

Product Specifications

Standard = Standard   Optional = Optional   Not Available = Not Available

Model 8.1m (26’7″)

Tractor Requirements

Minimum horse power 140hp
Minimum weight 6500kg / 14330lbs

Base Unit Mounting Options

Front mount Optional
Mid-mount Not Available
Rear mount Standard
Three point linkage (CAT II) Not Available
Axle bracket Standard

Overall machine parameters

Machine weight with head and oil 2490kg / 5490lbs
Capacity of oil tank 250 Litres / 66USG
Weight of machine with oil but without head 1955kg / 4310lbs

Controls

Cable control (CC) Optional
Low pressure hydraulics (LPH) Not Available
Electronic proportional control (EPP) Optional
Intelligent control system (ICS) Standard
Cable rotor reverse Standard
Electronic rotor reverse Optional

Hydraulic system

System capability 74hp
Pump flow rate 125 Litres / 33USG
Pump type (Gear / Piston / Helical) Gear
Pump arrangement (Twin / In-line) Twin
Independent hydraulics Standard
Oil cooler Standard

Arm features and main frame

Forward arm Not Available
Telescopic arm Standard
Telescopic arm stroke 1450mm / 4’9″
Power slew Standard
Power slew angle 180°
Gravity breakout protection Not Available
Hydraulic breakout protection Standard
Arm float – Manual operation Not Available
Arm float – Electronic operation Standard
Head float – Manual operation Optional
Head float – Electronic operation Standard
Left hand cutting Optional
Right hand cutting Optional
Left and right hand cutting Standard

Arm attachments available

Variable track bracket (VTB) Optional
Sheartrim cutter bar Optional
Pro-Saw Optional
Ditch cleaner Optional
Rotary head Optional

Accessories

Road lights Not Available
Debris blower Not Available
Cab guard kit Standard

Cutting Heads

1.2m Pro-Cut with 115mm Roller Optional
1.2m Pro-Cut with 150mm Roller Optional
1.5m Pro-Cut with 115mm Roller Optional
1.5m Pro-Cut with 150mm Roller Optional
1.2m Pro-Cut ISMP with 115mm Roller Optional
1.2m Pro-Cut ISMP with 150mm Roller Optional
2m HD Head Optional

Flails

See the table below to see which flail heads are available for the different cutting heads listed above.

  BB MP44 HS60 Pro Flail T40 T60 True Cut Bushmaster
1.2m Pro-Cut with 115mm roller Optional Optional Optional Optional Optional Optional Optional Optional
1.2m Pro-Cut with 150mm roller Optional Optional Optional Optional Optional Optional Optional Optional
1.5m Pro-Cut with 115mm roller Optional Optional Optional Optional Optional Optional Optional Optional
1.5m Pro-Cut with 150mm roller Optional Optional Optional Optional Optional Optional Optional Optional
1.2m Pro-Cut ISMP with 115mm roller Optional Optional Optional Optional Optional Optional Optional Optional
1.2m Pro-Cut ISMP with 150mm roller Optional Optional Optional Optional Optional Optional Optional Optional
2m HD head Optional Standard Not Available Not Available Not Available Not Available Not Available Not Available

Working Reach Dimensions

Head used to calculations: 1.2 Pro Cut


  8.1m (26’7″)
A 8.08m 26’6″
B 7.93m 26′
C 6.27m 20’7″
D 6.52m 21’5″
E 8.92m 29’3″
X 1.3m 4’1″
Y 1.0m 3’3″

Our range of Accessories for the B81.81

Attachments

A wide selection of attachments is available to improve the versatility and therefore the profitability of the Bomford arm mowers range.

Attachments

Controls

Every machine has a choice of tailormade control systems available on most arm mowers.

Controls

Flails

The vast majority of our heads now offer the ability to fit any one of eleven flail designs.

Flails

Heads

Most heads offer a choice of flails and ability to adjust rotor speed to suit verge or hedge.

Heads
